Welded Wire Mesh

Welded Wire Mesh
1. Factory direct sales, high-quality products, competitive prices
2. Pass ISO, CE and SGS certification every year
3. 24-hour fast service
4. Flexible payment methods (T/T, L/C, PayPal, Kunlun Bank)
5. Fast delivery, standard export packaging (can be packaged according to requirements)
6. Provide OEM/ODM services
7. Multiple shipping ports: Tianjin, Shanghai, Dalian, Qingdao, etc.
8. Free samples (shipping costs are borne by buyers)
9. Minimum order quantity: 1 ton

- Product Description -


Welded Wire Mesh Panels:

1):Height: 0.63m-3.0m
2):Width: 2.0m,2.2m,2.5m,3.0m(custom height and width is available)
3):Hole Opening: 50mmX50mm,50mmX100mm,50mmX150mm,50mmX200mm etc.
4):Wire Thickness: 3mm-8mm
5):Material: Low Carbon Steel Wire, Galvanized Wire
6):Finished: Electric Galvanized, Hot Dipped Galvanized, Polyester Painting,PVC Coated.

Fence Post:

1): peach post: 100mmX70mm,60mmX90mm,50mmX70mm

2): Square post: 60mmX40mm,60mmX60mm,60mmX80mm,80mmX80mm

3): Round post: 40mm-80mm
4): Thickness: 0.8mm-1.5mm
5): Length: On Request(Normal 0.65m-4m)
6): Finished: Hot Dipped Galvanized, electro galvanized,Polyester Painting(different colour)

Accessories of Welded Wire Fence:

1): Plastic Cap: Including Plastic Cap
2): Single Arm Or Double Arm: On Request
3): Tension Wire Or Barbed Wire: On Request
4): Concertina Razor Wire: On Request
5): Bolts & Nuts: According to Need


Specification List of Welded Wire Mesh

Opening

Wire Diameter

In inch

In metric unit(mm)

1/4" x 1/4"

6.4mm x 6.4mm

22,23,24

3/8" x 3/8"

10.6mm x 10.6mm

19,20,21,22

1/2" x 1/2"

12.7mm x 12.7mm

16,17,18,19,20,21,22,23

5/8" x 5/8"

16mm x 16mm

18,19,20,21,

3/4" x 3/4"

19.1mm x 19.1mm

16,17,18,19,20,21

1" x 1/2"

25.4mm x 12.7mm

16,17,18,19,20,21

1-1/2" x 1-1/2"

38mm x 38mm

14,15,16,17,18,19

1" x 2"

25.4mm x 50.8mm

14,15,16

2" x 2"

50.8mm x 50.8mm

12,13,14,15

2" x 4"

50.8mm x 101.6mm

12,13,14,15

4" x 4"

101.6mm x 101.6mm

12,13,14,15

4" x 6"

101.6mm x 152.4mm

12,13,14,15

6" x 6"

152.4mm x 152.4mm

12,13,14,15

6" x 8"

152.4mm x 203.2mm

12,13,14


- Product Display -

3

2

- Packaging And Transportation -

包装运输 1

- Application -

  • steel-bar-grating-panels
  • rebar-el-paso-1024x680
  • ogrodzenie-3d-globfence
  • 20220714_141231-scaled
  • STEEL-GRATING
  • 18

- Factory Showcase -

  • New-Steel-Mill-in-West-Virginia
  • H568af89fc0414a4bb1a229ff90ef2555H.jpg_720x720q50_副本
  • gratings
  • Grating
  • alfa_acciai_prodotti_barre_austria_acciaio_01_7128214b69_副本
  • 20220714_141541-1024x768
  • Steel-Rebar-6mm-9mm-12mm-Deformed-Steel-Rebar-Iron-Bar-Steel-Rebar-for-Construction-Supplier-Price_副本
  • steel-iStock-502120934

- Contact Us -

Submit
